High transparency
Low sheet resistance
PET-compatible process
Standard equipment stack
Water-based lift-off green edition
Metal recovery
FTO-oriented materials under NDA
/ TECHNOLOGY
The electrode geometry can be tuned for each application: line width, metal thickness, cell size, substrate, metal type and final electrode layout.
This makes the platform suitable for transparent heaters, antennas, EMI shielding, flexible electronics, sensors and optoelectronic devices.
This makes the platform suitable for transparent heaters, antennas, EMI shielding, flexible electronics, sensors and optoelectronic devices.
Self-organized template for transparent PVD metal mesh
At the core of Moonrise is a water-soluble active template green edition that forms a quasi-periodic cracked network during controlled drying. After activation, the template defines the geometry of a transparent metal mesh deposited by thermal evaporation or magnetron sputtering.
/ STEPS
Process flow
01
Template coating - a water-soluble template material is coated on PET, glass or another target substrate using slot-die coating.
02
Controlled crack formation - controlled drying creates a random micromesh pattern that defines the future conductive network.
03
Template activation - humidity and rapid drying create physical separation between metal at the bottom of the cracks and metal on the template sidewalls.
04
PVD metal deposition - Ag, Al, Cu or another metal is deposited by thermal evaporation or magnetron sputtering.
05
Water-based lift-off - the template is removed with water; the removed metal is captured for recovery and reuse.
06
Laser patterning - fiber-laser processing creates the final electrode topology, isolation zones, contact pads and custom layouts.
/ MANUFACTURING
Roll-to-roll-ready process built on standard industrial equipment
Moonrise is designed for industrial transfer. The process uses familiar manufacturing operations rather than custom laboratory-only tooling: coating, drying, PVD deposition, water treatment, metal recovery, laser patterning and web handling.
The standard equipment stack includes slot-die coating, thermal evaporation or magnetron sputtering, water-based lift-off, filtration and recovery modules, fiber-laser patterning and roll-to-roll web handling. This supports scale-up, partner-side integration and fast adaptation to existing production environments.
The platform can be configured around different cost-performance targets. Silver versions are suited for premium low-resistance applications; aluminium versions support cost-driven transparent electrodes; copper versions provide a path for specialized conductive structures with protective or barrier layers.
Standard equipment
Slot-die coating, PVD deposition, water lift-off, filtration and recovery, fiber laser and R2R web handling.
Low-cost potential
Material recovery, scalable equipment and aluminium-based versions support attractive total-cost targets.
R2R scalability
Process is compatible with roll-to-roll coating and continuous web-based manufacturing.
Fast adoption
Process steps are based on established industrial modules and can be transferred through licensing, JDA or JV models.
Product tuning
Geometry, substrate and metal choice can be adjusted for sheet resistance, transparency, haze, cost and product layout.
/ PERFORMANCE
Tunable random metal mesh for transparent conductive surfaces
A conductive random micromesh combines optical transparency, low sheet resistance and mechanical flexibility. Geometry and metal thickness are adjusted through process tuning to match the target application.
Structure
Transparent PVD metal-mesh electrode
Substrates
PET, glass and adaptable substrate formats
Metals
Ag, Al, Cu and application-specific metal stacks
Sheet resistance
Ag version: ≤ 2.5 Ohm/sq; Al version: ≤ 3.2 Ohm/sq
Optical transmittance
≤ 85% in current configurations; tunable through geometry optimization
Metal thickness
>1 micrometer in test structures
Flexibility
Bending radius <0.1 mm without Rs increase; 1,000 cycles at R=5 mm without degradation in test samples
Humidity stability
30 days at 21 C / 100% RH and 7 days at 85 C / 100% RH without Rs change in test samples
Flexibility
Bending radius <0.1 mm; 1,000 cycles at R=5 mm
EMI performance
>39 dB at 3.5 GHz with T >83%; up to ~30 dB in K-band transparent configurations
Pilot coating
R2R coating demonstrated at 0.6 m width and 6 m/min
Humidity stability
30 days at 21 C / 100% RH and 7 days at 85 C / 100% RH
Detailed test methods, uniformity maps, spectra, sample formats and application-specific data are available under NDA.
/ PRODUCT VERSIONS AND APPLICATIONS
One platform for multiple transparent electrode classes
Moonrise can be configured around Ag, Al and Cu versions to address different combinations of conductivity, optical performance, material cost and industrial requirements.
MOONRISE-Ag
Premium low-resistance transparent electrodes for highperformance surfaces. Flexible displays, transparent antennas, RIS surfaces, EMI glazing, high-performance transparent heaters, sensors and optoelectronic modules.
MOONRISE-Al
Cost-oriented transparent electrodes based on an abundant metal route. Display modules, transparent heaters, transportation surfaces, EMI films, large-area functional coatings and scalable conductive films.
MOONRISE-Cu
Conductive transparent structures for customized stacks and protected formats. Antennas, EMI shielding, hybrid conductive surfaces, specialized electronics and multilayer transparent conductive systems.
/ APPLICATIONS
Application Areas
/ CIRCULAR MANUFACTURING AND VALIDATION
Circular Manufacturing and Validation
Moonrise combines performance with clean production logic: water-based template removal, captured metal recovery and recyclable process materials.
Circular manufacturing
The process is designed to support hazardous-waste reduction, supplier ESG audits and industrial qualification.
Recovered metal can be converted into functional secondary materials, including silver microflakes, conductive pastes, EMI materials and specialized composites.
This makes circular manufacturing part of the process economics, not an additional marketing layer.
Recovered metal can be converted into functional secondary materials, including silver microflakes, conductive pastes, EMI materials and specialized composites.
This makes circular manufacturing part of the process economics, not an additional marketing layer.
Validation and IP/FTO materials
Moonrise is based on a dedicated PVD metal-mesh architecture using self-organized templates, PVD metallization, water-based lift-off and laser-defined topology.
Patent family overview, FTO-oriented materials and claim charts are available under NDA for licensing, joint development and technology-transfer discussions.
Patent family overview, FTO-oriented materials and claim charts are available under NDA for licensing, joint development and technology-transfer discussions.
Patents
protected technology platform and patent-family materials available for technical and legal review.
Publications
peer-reviewed publications and technical data supporting the underlying electrode performance.
Spectra and graphs
optical transmittance spectra, resistance-transmittance data and application-specific performance graphs.
Qualification package
samples, test methods, reliability data, uniformity maps and process information available under NDA.
FTO-oriented package
claim charts and architecture comparison available for licensing and JDA discussions.
Start a technical conversation
Moonrise is available for technology sale, licensing, joint development, joint venture and strategic technology-transfer discussions.
Request samples, a technical datasheet or an NDA-based review package to evaluate the platform for your application.
